Станция паяльная Weller, WAD-101

Станция паяльная Weller, WAD-101

Станция паяльная Weller, WAD-101
Станция паяльная Weller, WAD-101
Hot air soldering station in ESD-safe design for connection to pneumatic air. For touch-free soldering/desoldering of surface-mounted components. A microprocessor controls the equipment and digital regulation electronics optimises the use of various soldering tools by identifying each and every one of them and assigning a fitting regulation parameter to each tool. Effective heating elements (24 V) contribute to this dynamic regulation. When a soldering iron is connected, the temperature range is automatically limited to 450 °C. Desired and actual values are both displayed digitally. Potential balancing of the soldering tip. Comes with a HAP 1 hot air soldering iron with integrated pushbutton, but can also be equipped with LR 21, MLR 21, MPR 30 and WSP 80.
Supplied with control unit, stand AK 20 with cleaning sponge, pneumatic air connection, hot air soldering iron HAP 1 with 2 pcs. of hot air nozzles with the inner diameters 1.2 and 3.0 mm, tip-changing tool, a transformer as well as a manual.
Power, hot air: 100 W
Temperature range
hot air: 50–550 °C
soldering iron: 50–450 °C
Supply pressure: 400 kPa
Air consumption: 0–10 l/min.
Voltage
primary: 230 Vac/50 Hz
secondary: 24 Vac
Dimensions: W115×L180×H101 mm
Weight: 2.0 kg


Информация
Код товара 18141
Производитель Weller
Артикул производителя 53266699
Условия поставки Под заказ
